Hash-chained agent audit trail specification

This specification defines a minimal public format for reviewing a tamper-evident agent execution history. It is intentionally implementation-neutral. The format can be produced by a single agent, a multi-agent orchestrator, or a conventional application that delegates actions to models and tools.

The design goal is narrower than immutability. A verifier should be able to detect whether the retained chain changed after it was committed. Authenticity, completeness, privacy, authorization, and durable retention require additional controls described below.

What must an agent audit trail record?

An agent audit record must connect identity, intent, authority, execution, and outcome. A text log saying that an agent "completed the task" is not enough for an investigator to reconstruct what happened.

Identity and delegation

Record the accountable human or service, the acting agent, the tenant or security boundary, and the delegation that allowed the agent to act. A model name is not an identity. A session identifier is not authority. The record should make it possible to answer who initiated the work and who remained responsible for it.

Task and action classification

Record the bounded task, the proposed action, the target resource, and the consequence class used by policy. Reading a public reference and transferring funds may both be "tool calls," but treating them as one event type prevents meaningful review.

Policy and approval

Record the policy decision, policy version, attributes evaluated, and any human approval. Approval must bind the exact parameters reviewed. A generic approval token that can be reused for a changed recipient, amount, destination, or data scope is not reliable evidence of consent.

Execution and outcome

Record the tool request through a protected representation, the downstream response or receipt, the resulting state, and any failure or retry. The audit event should distinguish "requested," "accepted," "completed," and "verified" rather than compressing them into one success flag.

Release context

Record the software release, model endpoint, policy bundle, tool adapter, and schema version relevant to the action. Without version references, the trail cannot explain which behavior or control was actually in force.

Which fields are in the public reference format?

The following table separates required linkage fields from recommended operational fields. Deployments may add fields, but removing required fields changes the profile.

Field	Required	Purpose	Privacy guidance
chain_id	Yes	Names one ordered record stream	Use a non-secret opaque identifier
sequence	Yes	Establishes strict order inside the chain	Integer, starting rule must be documented
recorded_at	Yes	States when the event was committed	Use UTC with explicit precision
event_type	Yes	Classifies the lifecycle or control event	Use a versioned closed vocabulary
actor	Yes	Identifies the human, service, or agent	Prefer stable internal IDs over email addresses
on_behalf_of	Recommended	Identifies the principal represented	Required when an agent acts for another party
task_id	Yes	Links events from one bounded task	Must not expose customer content
action	Yes	Describes the proposed or completed operation	Separate verb, resource, and parameter reference
authority	Yes	Names the evaluated policy or grant	Include decision and version
approval	Conditional	Links parameter-bound human review	Required when policy calls for review
outcome	Yes	Records result and state transition	Distinguish proposed, denied, failed, and completed
evidence_refs	Recommended	Links receipts, attestations, or protected artifacts	Apply access checks at retrieval time
schema_version	Yes	Selects canonicalization and validation rules	Version every incompatible change
previous_hash	Yes	Commits to the preceding record	Fixed-length lowercase hexadecimal in this profile
hash	Yes	Commits to this record and predecessor	Computed after canonicalization

The public verifier on this site uses a reduced subset so a reader can inspect the chain without uploading real data. Production deployments normally need more identity, policy, evidence, and tenancy context than the browser example.

How is each record canonicalized and hashed?

The hash input must be deterministic. This profile uses UTF-8 encoded canonical JSON and a domain-separated prefix. RFC 8785 is a useful baseline for canonical JSON because it defines deterministic property sorting and primitive serialization.

Reference construction

payload = canonicalize(record_without_hash_and_previous_hash)
input   = "TRUNNION-AUDIT-REF-V1\n" || previous_hash || "\n" || payload
hash    = lowercase_hex(SHA-512(UTF8(input)))

The first record uses a documented genesis value. This profile uses 128 lowercase zeroes, the width of a SHA-512 hexadecimal digest. A deployment may use a signed chain-opening record instead, but the choice must be explicit.

Reference JSON

{
  "chain_id": "ach_01J7REFERENCE",
  "sequence": 42,
  "recorded_at": "2026-09-20T14:06:31.482Z",
  "event_type": "approval.resolved",
  "actor": { "type": "human", "id": "usr_8421" },
  "on_behalf_of": { "type": "organization", "id": "org_104" },
  "task_id": "task_9018",
  "action": {
    "verb": "release",
    "resource": "requirement_summary",
    "parameters_digest": "sha512:..."
  },
  "authority": {
    "policy_id": "policy.release-review",
    "policy_version": "17",
    "decision": "allow"
  },
  "approval": {
    "approval_id": "apr_392",
    "decision": "approved",
    "parameters_digest": "sha512:..."
  },
  "outcome": { "state": "completed", "receipt_ref": "receipt_551" },
  "evidence_refs": ["evidence://receipt_551"],
  "schema_version": "aat-ref-1",
  "previous_hash": "0f4d...",
  "hash": "9b16..."
}

The example uses digests and references for sensitive parameters. A digest is not encryption, and low-entropy values may still be guessed. Whether a field is retained, tokenized, encrypted, or excluded belongs to the deployment's data-handling design.

How should a verifier check the chain?

Verification is a repeatable procedure, not a visual "verified" badge.

1. Parse the records with strict size and count limits.
2. Validate every record against the declared schema version.
3. Confirm that all records carry the same chain_id unless a rollover event explicitly changes it.
4. Confirm that sequence numbers are contiguous and follow the stated starting rule.
5. Confirm that record one references the documented genesis value or signed opening record.
6. Rebuild the canonical payload for each record.
7. Recompute the digest using the stored predecessor.
8. Compare the computed digest with the stored digest using an exact byte comparison.
9. Confirm that the next record's previous_hash equals the current record's digest.
10. Validate any external checkpoint, signature, or inclusion proof using separately trusted material.
11. Report the first divergence, the verification scope, and the checkpoint used.

Verification pseudocode

previous = GENESIS
expected_sequence = 1

for record in ordered_records:
    require record.sequence == expected_sequence
    require record.previous_hash == previous
    validate(record, schema=record.schema_version)
    payload = canonicalize(without_linkage(record))
    computed = sha512(PREFIX + "\n" + previous + "\n" + payload)
    require constant_time_equal(computed, record.hash)
    previous = computed
    expected_sequence += 1

verify_checkpoint(previous, checkpoint)

The verifier must say what it did not check. A valid local chain with no trusted checkpoint may show internal consistency while remaining replaceable as a whole.

Which attacks should verification detect?

Test mutation	Expected result	Why it matters
Edit one retained field	Digest mismatch at that record	Detects changed history
Delete a middle record	Sequence or predecessor mismatch	Detects omission from the retained series
Insert a new middle record	Next predecessor mismatch	Detects unauthorized insertion
Reorder two records	Sequence and predecessor mismatch	Protects causal ordering
Truncate the tail	Local chain may still verify	Requires a separately trusted checkpoint
Replace the whole chain	Local chain may still verify	Requires signature, witness, or external anchor
Omit an event before logging	Chain still verifies	Requires boundary coverage tests
Copy a valid record to another tenant	Schema may still validate	Requires tenant-bound identity and query enforcement

These negative tests belong in release evidence. A verifier that has only seen a valid sample has not demonstrated detection behavior.

How do checkpoints and signatures strengthen the trail?

A checkpoint commits to a chain head outside the writer's immediate control. It may be written to a separately administered store, signed by a protected key, witnessed by another service, or represented as a Merkle tree head. The right pattern depends on threat model and scale.

Local signed checkpoints

A protected signing service periodically signs the chain identifier, highest sequence, latest digest, schema version, and checkpoint time. Verification requires the public key, certificate history, revocation status, and rotation record. A signature is valuable only if the chain writer cannot also rewrite key history without detection.

External witnesses

A deployment can send only a checkpoint digest, not the underlying sensitive records, to a separately controlled witness. This reduces disclosure while making whole-chain replacement harder. Disconnected deployments can export checkpoints through an authorized transfer process rather than relying on continuous connectivity.

Merkle transparency structures

Large systems may batch records into a Merkle tree and retain signed tree heads. This supports inclusion and consistency proofs without replaying the entire history for every query. RFC 9162 is a mature transparency-log reference, but an agent system still needs its own event model, tenancy rules, and failure behavior.

What are the main operational trade-offs?

Design choice	Benefit	Cost or risk	Decision evidence
Hash every event synchronously	Immediate linkage	Adds write-path latency and dependency	Release load test and failure policy
Queue before hashing	Isolates action latency	Creates a window before durable commitment	Queue durability and reconciliation test
Retain full arguments	Easier reconstruction	Higher sensitivity and storage cost	Data classification and access review
Retain protected references	Lower log exposure	Evidence retrieval has more dependencies	Reference durability and authorization test
Sign every record	Strong per-record authenticity	Key operations and rotation overhead	Key custody and throughput evidence
Sign periodic checkpoints	Lower signing cost	Smaller undetected window	Checkpoint frequency rationale
Linear chain	Simple verification	Full scans grow with record count	Verification-time budget
Merkle batches	Efficient proofs	More complex implementation and operations	Independent proof test vectors

There is no universally correct interval, retention period, or checkpoint method. A credible specification names the variables and the evidence used to choose them.

How should the system behave when recording fails?

Failure behavior should follow consequence. A system that continues a high-impact tool action after losing its audit boundary creates an unreviewable side effect. A system that blocks every low-risk read during a short logging interruption may create needless fragility.

Define at least three policies:

Fail closed

Actions that change durable state, transfer data, create an external commitment, alter permissions, or affect a person should normally stop before execution when the required audit commitment cannot be made.

Queue with a bounded lease

Some actions can remain pending for a short, visible period. The queue must be durable, bounded, observable, and incapable of executing after its authority expires.

Continue with explicit degraded evidence

Only actions whose consequence and data exposure permit it may continue. The degraded state must create its own operator-visible event and reconciliation obligation. "Best effort" without a named owner and deadline is not a control.

What privacy and tenancy rules apply?

Audit data often becomes the most concentrated record of a system's work. It may contain identities, document references, decisions, denials, and failure details. Treat it as a protected product surface.

• Partition storage and queries by deployment and tenant before retrieval, not through a post-query filter.
• Separate broad operational telemetry from decision records.
• Encrypt data at rest and in transit according to the deployment's requirements.
• Apply ABAC or comparably contextual authorization to audit queries and exports.
• Define field-level retention instead of assuming one period fits every record.
• Record authorized redaction or correction as a new event rather than silently rewriting history.
• Test cross-tenant denial, unauthorized export, expired access, and revoked reviewer credentials.

The chain protects evidence integrity only when the people and systems reading it are governed too.

How should buyers evaluate a vendor claim?

Ask for an artifact from the exact release and environment under consideration. The evidence package should include the record schema, canonicalization version, negative verification tests, boundary-coverage map, failure behavior, checkpoint design, key custody, cross-tenant tests, retention rules, and a supported export procedure.

The IETF Agent Audit Trail document is an Internet-Draft and may change or expire. It is useful as a public point of comparison, not as proof that an implementation is standards-compliant. FIPS 180-4 defines the underlying hash algorithms, not the application event model. RFC 8785 defines canonical JSON, not authorization or completeness. A credible audit design composes these pieces and states what each one contributes.
